25 SB160 T-Series
25 SB160 T-Series
Upholding a time-tested, race-bred ethos that says nothing should hold a rider back from the sheer joy of untethered speed. Built off one of the most winning race platform in EWS history, the SB160 is pure race machinery. Honed for more. Be fastest.
From Legacy to dynasty, the Yeti/Fox Factory Team won 49 EWS stages, 11 EWS races and 1 national series championships aboard the SB150. The SB160 builds momentum on this legacy of excellence. Honed. Refined. Even effing faster.
Frame Highlights:
NEW Switch Infinity assembly on T-Series
NEW Threaded bottom bracket
NEW High-clearance downtube
NEW Dual-density downtube protection
Universal Derailleur Hanger (UDH)
Secure, fully enclosed internal cable management
Compatible with long dropper posts
100% standard sealed Enduro Max bearings
Floating collet axle pivot design
Compact-wishbone shock extender
Downhill tested
Yeti/Fox Factory team approved
Boost spacing.
SIZING:
Small – 155 CM – 170 CM
Medium – 165 CM – 180 CM
Large – 178 CM – 191 CM
X-Large – 185 CM – 201 CM
XX-Large – 195 CM – 210 CM
WARRANTY:
Lifetime
COLOURS:
Raw Carbon, Mustard, Turquoise
FRAME TRAVEL:
160mm using Switch Infinity suspension technology
FORK TRAVEL:
170mm
WHEEL SIZE:
29″
PRICING:
T-Series Frame Only – $7,500
T-Series SRAM GX AXS T-Type – $12,800
T-Series SRAM XO AXS T-Type (RockShox) – $13,900
T-Series SRAM XO AXS T-Type (Fox Factory) – $14,800
T-Series SRAM XX AXS T-Type – $16,900
SPECS:
- SRAM GX AXS T-TYPE
- SRAM XO AXS T-TYPE RX
- SRAM XO AXS T-TYPE FX
- SRAM XX AXS T-TYPE
SB160 | TURQ SERIES CARBON |
Fork | ROCK SHOX ZEB ULTIMATE 170MM |
Shock | FOX FACTORY X2 |
Headset | CANE CREEK INTEGRATED |
Bar | RACE FACE AEFFECT R 35X780MM |
Stem | RACE FACE AEFFECT R 35X50MM |
Grips | RACE FACE GRIPPLER |
Crank | SRAM GX EAGLE 32T / T-TYPE W/GUARD |
Rear Der. | SRAM GX AXS T-TYPE |
Cassette | 1275 EAGLE 10X52 T-TYPE |
Shifter | AXS POD RIGHT BRIDGE |
Brakes | SRAM CODE BRONZE |
F. Rotor | CENTRELINE 220 |
R. Rotor | CENTRELINE 200 |
Post | ONE UP DROPPER |
Wheelset | DT E1900 WHEELSET 29 / 30MM |
Tire Front | MAXXIS ASSEGAI EXO + 29 x 2.5 |
Tire Rear | MAXXIS MINION DHR EXO + 29 x 2.4 |
Saddle | WTB SILVERADO 142MM YETI |
Guide | E13 TRS+ |
SB160 | TURQ SERIES CARBON |
Fork | ROCK SHOX ZEB ULTIMATE 170MM |
Shock | FOX FACTORY X2 |
Headset | CANE CREEK INTEGRATED |
Bar | RACE FACE NEXT R 35X800MM |
Stem | RACE FACE TURBINE 35X50MM |
Grips | RACE FACE GRIPPLER |
Crank | SRAM XO EAGLE 32T / T-TYPE W/GUARD |
Rear Der. | SRAM XO AXS T-TYPE |
Cassette | 1295 EAGLE 10X52 T-TYPE |
Shifter | AXS POD ULTIMATE RIGHT BRIDGE |
Brakes | SRAM MAVEN SILVER |
F. Rotor | SRAM HS2 220 |
R. Rotor | SRAM HS2 200 |
Post | ONE UP DROPPER |
Wheelset | DT 350 W / DT EX511 30MM |
Tire Front | MAXXIS ASSEGAI EXO + 29 x 2.5 |
Tire Rear | MAXXIS MINION DHR EXO + 29 x 2.4 |
Saddle | WTB SILVERADO 142MM YETI |
Guide | E13 TRS+ |
SB160 | TURQ SERIES CARBON |
Fork | FOX FACTORY 38 170MM GRIP 2 |
Shock | FOX FACTORY X2 |
Headset | CANE CREEK INTEGRATED |
Bar | RACE FACE NEXT R 35X800MM |
Stem | RACE FACE TURBINE 35X50MM |
Grips | RACE FACE GRIPPLER |
Crank | SRAM XO EAGLE 32T / T-TYPE W/GUARD |
Rear Der. | SRAM XO AXS T-TYPE |
Cassette | 1295 EAGLE 10X52 T-TYPE |
Shifter | AXS POD ULTIMATE RIGHT BRIDGE |
Brakes | SRAM MAVEN SILVER |
F. Rotor | SRAM HS2 220 |
R. Rotor | SRAM HS2 200 |
Post | FOX FACTORY TRANSFER |
Wheelset | DT 350 W / DT EX511 30MM |
Tire Front | MAXXIS ASSEGAI EXO + 29 x 2.5 |
Tire Rear | MAXXIS MINION DHR EXO + 29 x 2.4 |
Saddle | WTB SILVERADO 142MM YETI |
Guide | E13 TRS+ |
SB160 | TURQ SERIES CARBON |
Fork | FOX FACTORY 38 170MM GRIP 2 |
Shock | FOX FACTORY X2 |
Headset | CHRIS KING |
Bar | RACE FACE NEXT R 35X800MM |
Stem | RACE FACE TURBINE 35X50MM |
Grips | ODI ELITE PRO |
Crank | SRAM XX EAGLE 32T / T-TYPE W/GUARD |
Rear Der. | SRAM XX AXS T-TYPE |
Cassette | 1297 EAGLE 10X52 T-TYPE |
Shifter | AXS POD ULTIMATE RIGHT BRIDGE |
Brakes | SRAM MAVEN ULTIMATE |
F. Rotor | SRAM HS2 220 |
R. Rotor | SRAM HS2 200 |
Post | FOX FACTORY TRANSFER |
Wheelset | DT XMC 1501 – CARBON |
Tire Front | MAXXIS ASSEGAI EXO + 29 x 2.5 |
Tire Rear | MAXXIS MINION DHR EXO + 29 x 2.4 |
Saddle | WTB SILVERADO 142MM YETI |
Guide | E13 TRS+ |
AXS DROPPER POST OPTION > + $395 |
